在线询价直流无刷风扇（BLDC）
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 宽度 | 气流 | 静压 | 轴承类型 | 风扇类型 | 特性 | 噪音 | 功率（瓦特） | 转速（RPM） | 端接方式 | 防护等级 | 工作温度 | 认证机构 | 重量 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
109P0424B3023FAN AXIAL 40X28MM 24VDC WIRE |
4,697 |
|
规格书 |
San Ace 40 | Box | Active | 24VDC | Square - 40mm L x 40mm H | 28.00mm | 13.4 CFM (0.375m³/min) | 0.574 in H2O (143.0 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 40.0dB(A) | 3.12 W | 10300 RPM | 2 Wire Leads | - | -4 ~ 140°F (-20 ~ 60°C) | CSA, TUV, UL | 0.115 lb (52.16 g) |
|
|
109P0412A30240X28MM 12V DC 0 |
4,271 |
|
规格书 |
San Ace 40 | Box | Active | 12VDC | Square - 40mm L x 40mm H | 28.00mm | - | - | Ball | Tubeaxial | Locked Rotor Protection | 24.0dB(A) | - | 5100 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CSA, TUV, UR | - |
|
|
DC0301005H2B-3T3FAN 30X10MM 5VDC TACH MOLEX 22-0 |
2,264 |
|
规格书 |
- | Bulk | Active | 5VDC | Square - 30mm L x 30mm H | 10.50mm | 4.5 CFM (0.126m³/min) | 0.210 in H2O (52.3 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 29.0dB(A) | 350 mW | 9000 RPM | 3 Position Rectangular Connector | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus | - |
|
|
DC0301005L2B-3T3FAN 30X10MM 5VDC TACH MOLEX 22-0 |
1,508 |
|
规格书 |
- | Bulk | Active | 5VDC | Square - 30mm L x 30mm H | 10.50mm | 3.0 CFM (0.084m³/min) | 0.090 in H2O (22.4 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 17.0dB(A) | 150 mW | 6000 RPM | 3 Position Rectangular Connector | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus | - |
|
|
DC0301005M2B-3T3FAN 30X10MM 5VDC TACH MOLEX 22-0 |
3,749 |
|
规格书 |
- | Bulk | Active | 5VDC | Square - 30mm L x 30mm H | 10.50mm | 3.7 CFM (0.104m³/min) | 0.140 in H2O (34.9 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 24.0dB(A) | 250 mW | 7500 RPM | 3 Position Rectangular Connector | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus | - |
|
|
DC0251012L2B-BT4FAN 25X10MM 12VDC PWM/TACH MOLEX |
1,222 |
|
规格书 |
- | Bulk | Active | 12VDC | Square - 25mm L x 25mm H | 10.00mm | 1.3 CFM (0.036m³/min) | 0.070 in H2O (17.4 Pa) | Ball | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 20.0dB(A) | 600 mW | 7000 RPM | 4 Position Rectangular Connector | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
DC0251012M2B-BT4FAN 25X10MM 12VDC PWM/TACH MOLEX |
1,861 |
|
规格书 |
- | Bulk | Active | 12VDC | Square - 25mm L x 25mm H | 10.00mm | 1.9 CFM (0.053m³/min) | 0.170 in H2O (42.3 Pa) | Ball | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 24.0dB(A) | 720 mW | 10000 RPM | 4 Position Rectangular Connector | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
BFB1012HHFAN BLOWER 97.2X33MM 12VDC WIRE |
4,642 |
|
规格书 |
BFB | Bulk | Obsolete | 12VDC | Rectangular/Rounded - 97.2mm L x 94.4mm H | 33.00mm | 28.3 CFM (0.792m³/min) | 1.300 in H2O (323.6 Pa) | Ball | Blower | Locked Rotor Protection | 55.0dB(A) | 13.2 W | 4000 RPM | 2 Wire Leads | - | 14 ~ 140°F (-10 ~ 60°C) | CE, CSA, UL, VDE | 0.353 lb (160.12 g) |
|
|
G4028H12B-RSRFAN AXIAL 40X28MM 12VDC WIRE |
4,626 |
|
规格书 |
G4028 | Bulk | Active | 12VDC | Square - 40mm L x 40mm H | 28.00mm | 16.0 CFM (0.448m³/min) | 0.570 in H2O (142.0 Pa) | Ball | Tubeaxial | Thermal Overload Protector (TOP) | 41.0dB(A) | - | 10000 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.111 lb (50.35 g) |
|
|
G4028M12B-RSRFAN AXIAL 40X28MM 12VDC WIRE |
4,206 |
|
规格书 |
G4028 | Bulk | Active | 12VDC | Square - 40mm L x 40mm H | 28.00mm | 13.0 CFM (0.364m³/min) | 0.370 in H2O (92.2 Pa) | Ball | Tubeaxial | Thermal Overload Protector (TOP) | 37.0dB(A) | - | 8000 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.111 lb (50.35 g) |
|
|
G4028M24B-RSRFAN AXIAL 40X28MM 24VDC WIRE |
2,153 |
|
规格书 |
G4028 | Bulk | Active | 24VDC | Square - 40mm L x 40mm H | 28.00mm | 13.0 CFM (0.364m³/min) | 0.370 in H2O (92.2 Pa) | Ball | Tubeaxial | Thermal Overload Protector (TOP) | 37.0dB(A) | - | 8000 RPM | 2 Wire Leads | - | - | CE, cUL, TUV, UL | 0.111 lb (50.35 g) |
|
|
DC0602548H2B-BT0FAN 60X25MM 48VDC PWM/TACH |
1,145 |
|
规格书 |
- | Bulk | Active | 48VDC | Square - 60mm L x 60mm H | 25.00mm | 33.6 CFM (0.941m³/min) | 0.250 in H2O (62.3 Pa) | Ball | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 40.0dB(A) | 13.44 W | 5000 RPM | 4 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus | - |
|
|
DC0602548L2B-BT0FAN 60X25MM 48VDC PWM/TACH |
2,266 |
|
规格书 |
- | Bulk | Active | 48VDC | Square - 60mm L x 60mm H | 25.00mm | 21.5 CFM (0.602m³/min) | 0.160 in H2O (39.8 Pa) | Ball | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 31.0dB(A) | 5.76 W | 3600 RPM | 4 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus | - |
|
|
DC0602548J2B-BT0FAN 60X25MM 48VDC PWM/TACH |
2,898 |
|
规格书 |
- | Bulk | Active | 48VDC | Square - 60mm L x 60mm H | 25.00mm | 17.1 CFM (0.479m³/min) | 0.120 in H2O (29.9 Pa) | Ball | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 26.0dB(A) | 9.6 W | 3100 RPM | 4 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus | - |
|
|
DC0602548M2B-BT0FAN 60X25MM 48VDC PWM/TACH |
2,693 |
|
规格书 |
- | Bulk | Active | 48VDC | Square - 60mm L x 60mm H | 25.00mm | 24.0 CFM (0.672m³/min) | 0.220 in H2O (54.8 Pa) | Ball | Tubeaxial | Locked Rotor Protection, PWM Control, Speed Sensor (Tach) | 34.0dB(A) | 7.2 W | 4250 RPM | 4 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus | - |
|
CFM-9238S-250-532-20FAN AXIAL 92X37.5MM 24VDC WIRE |
3,770 |
|
规格书 |
CFM-92S | Box | Active | 24VDC | Square - 92mm L x 92mm H | 37.50mm | 92.0 CFM (2.58m³/min) | 0.630 in H2O (156.9 Pa) | Sleeve | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 52.3dB(A) | 12.48 W | 4800 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
OD1238-48HSSFAN AXIAL 120X38.5MM 48VDC WIRE |
1,770 |
|
规格书 |
OD1238 | Bulk | Active | 48VDC | Square - 120mm L x 120mm H | 38.50mm | 100.0 CFM (2.80m³/min) | 0.280 in H2O (69.7 Pa) | Sealed Sleeve | Tubeaxial | - | 42.0dB | 4.8 W | 3000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | cURus, TUV | - |
|
|
OD1238-48LSSFAN AXIAL 120X38.5MM 48VDC WIRE |
4,542 |
|
规格书 |
OD1238 | Bulk | Active | 48VDC | Square - 120mm L x 120mm H | 38.50mm | 65.0 CFM (1.82m³/min) | 0.130 in H2O (32.4 Pa) | Sealed Sleeve | Tubeaxial | - | 26.0dB | 3.36 W | 2000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | cURus, TUV | - |
|
|
OD1238-48MSSFAN AXIAL 120X38.5MM 48VDC WIRE |
4,402 |
|
规格书 |
OD1238 | Bulk | Active | 48VDC | Square - 120mm L x 120mm H | 38.50mm | 79.0 CFM (2.21m³/min) | 0.210 in H2O (52.3 Pa) | Sealed Sleeve | Tubeaxial | - | 33.0dB | 3.8 W | 2550 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | cURus, TUV | - |
|
AFB0812HB-F00FAN AXIAL 80X15MM 12VDC WIRE |
3,385 |
|
规格书 |
AFB | Box | Active | 12VDC | Square - 80mm L x 80mm H | 15.00mm | 33.5 CFM (0.938m³/min) | 0.138 in H2O (34.3 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 34.0dB(A) | 1.68 W | 3100 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.128 lb (58.06 g) |
