在线询价固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CSAB0740-150MSMD MOLDING POWER CHOKE CODACA |
989 |
|
规格书 |
CSAB0740 | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 15 µH | ±20% | 3.7 A | 4.5A | Shielded | 95mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.285" L x 0.260" W (7.25mm x 6.60mm) | 0.157" (4.00mm) |
|
|
CSAB0750-4R7MSMD MOLDING POWER CHOKE CODACA |
795 |
|
规格书 |
CSAB0750 | 2-SMD | Cut Tape (CT) | Active | Molded | Alloy Powder | 4.7 µH | ±20% | 6.6 A | 7A | Shielded | 32mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Low DCR, Low Loss | Surface Mount | 2-SMD | 0.285" L x 0.260" W (7.25mm x 6.60mm) | 0.189" (4.80mm) |
|
|
CSAB0420-R33MSMD MOLDING POWER CHOKE CODACA |
490 |
|
规格书 |
CSAB0420 | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 0.33 µH | ±20% | 9.9 A | 12A | Shielded | 10.5mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Molded Inductors, Molding Power Choke | Surface Mount | 2-SMD | 0.173" L x 0.165" W (4.40mm x 4.20mm) | 0.079" (2.00mm) |
|
|
CSAB0420-R10MSMD MOLDING POWER CHOKE CODACA |
490 |
|
规格书 |
CSAB0420 | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 0.1 µH | ±20% | 15.6 A | 28A | Shielded | 4.0mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Molded Inductors, Molding Power Choke | Surface Mount | 2-SMD | 0.173" L x 0.165" W (4.40mm x 4.20mm) | 0.079" (2.00mm) |
|
|
CSAB0730-4R7MSMD MOLDING POWER CHOKE CODACA |
3,000 |
|
规格书 |
CSAB0730 | 2-SMD | Tape & Reel (TR) | Active | Molded | Alloy Powder | 4.7 µH | ±20% | 5.5 A | 9.5A | Shielded | 40mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Low DCR, Low Loss | Surface Mount | 2-SMD | 0.285" L x 0.260" W (7.25mm x 6.60mm) | 0.118" (3.00mm) |
|
|
CSAB0730-1R5MSMD MOLDING POWER CHOKE CODACA |
984 |
|
规格书 |
CSAB0730 | 2-SMD | Cut Tape (CT) | Active | Molded | Alloy Powder | 1.5 µH | ±20% | 10.9 A | 14A | Shielded | 12.1mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Low DCR, Low Loss | Surface Mount | 2-SMD | 0.285" L x 0.260" W (7.25mm x 6.60mm) | 0.118" (3.00mm) |
|
|
CSAC0730-R22MSMD MOLDING POWER CHOKE CODACA |
984 |
|
规格书 |
CSAC0730 | 2-SMD | Cut Tape (CT) | Active | Molded | Carbonyl Powder | 220 nH | ±20% | 21 A | 35A | Shielded | 3.2mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Low DCR, Low Loss | Surface Mount | 2-SMD | 0.285" L x 0.260" W (7.25mm x 6.60mm) | 0.118" (3.00mm) |
|
CSAB0530-4R7MSMD MOLDING POWER CHOKE CODACA |
9,143 |
|
规格书 |
CSAB0530 | Nonstandard | Tape & Reel (TR) | Active | Molded | Alloy Powder | 4.7 µH | ±20% | 4.1 A | 5A | Shielded | 60mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.213" L x 0.197" W (5.40mm x 5.00mm) | 0.118" (3.00mm) |
|
|
CSAB0530-1R0MSMD MOLDING POWER CHOKE CODACA |
1,979 |
|
规格书 |
CSAB0530 | 2-SMD | Cut Tape (CT) | Active | Molded | Alloy Powder | 1 µH | ±20% | 8.7 A | 12A | Shielded | 14mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | Low DCR, Low Loss | Surface Mount | 2-SMD | 0.213" L x 0.205" W (5.40mm x 5.20mm) | 0.118" (3.00mm) |
|
|
CSAB0530-5R6MSMD MOLDING POWER CHOKE CODACA |
1,970 |
|
规格书 |
CSAB0530 | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 5.6 µH | ±20% | 3.9 A | 4.5A | Shielded | 65mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.213" L x 0.205" W (5.40mm x 5.20mm) | 0.118" (3.00mm) |
