在线询价模拟开关、复用器、解复用器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 开关电路 | 多路复用器/解复用器电路 | 电路数量 | 导通状态电阻（最大） | 通道与通道匹配（ΔRon） | 电压 - 供应，单（V+） | 电压 - 供应，双（V±） | 开关时间（Ton, Toff）（最大） | -3db 带宽 | 电荷注入 | 通道电容（CS(off), CD(off)） | 漏电流（IS(off)）（最大） | 串扰 | 工作温度 | 等级 | 认证 | 安装类型 | 供应商设备封装 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DG528DN+IC MUX 8:1 450OHM 20PLCC |
2,200 |
|
规格书 |
- | Tube | Obsolete | - | 8:1 | 1 | 450Ohm | 27Ohm | 5V ~ 30V | ±4.5V ~ 20V | 1.5µs, 1.5µs | - | 4pC | 5pF, 25pF | 5nA | - | -40°C ~ 85°C (TA) | - | - | Surface Mount | 20-PLCC (9x9) |
|
|
DG301AC/DIC SWITCH SPDT X 1 50OHM DIE |
2,957 |
|
规格书 |
- | Tray | Obsolete | SPDT | 2:1 | 1 | 50Ohm | - | 5V ~ 18V | ±5V ~ 18V | 300ns, 250ns | - | 12pC | 14pF, 14pF | 5nA | -74dB @ 500kHz | 0°C ~ 70°C (TA) | - | - | Surface Mount | Die |
|
|
DG507AC/DIC MUX DUAL 8:1 400OHM DIE |
3,182 |
|
规格书 |
- | Tray | Obsolete | - | 8:1 | 2 | 400Ohm | 27Ohm | 4.5V ~ 18V | ±4.5V ~ 18V | 1µs, 400ns (Typ) | - | - | 6pF, 23pF | 5nA | - | 0°C ~ 70°C (TA) | - | - | Surface Mount | Die |
|
|
DG308AC/DIC SWITCH SPST-NO X 4 100OHM DIE |
2,043 |
|
规格书 |
- | Tray | Obsolete | SPST - NO | 1:1 | 4 | 100Ohm | - | 5V ~ 30V | ±5V ~ 20V | 200ns, 150ns | - | -10pC | 11pF, 8pF | 5nA | - | 0°C ~ 70°C (TA) | - | - | Surface Mount | Die |
|
|
DG528DN+TIC MUX 8:1 450OHM 20PLCC |
3,668 |
|
规格书 |
- | Tape & Reel (TR) | Obsolete | - | 8:1 | 1 | 450Ohm | 27Ohm | 5V ~ 30V | ±4.5V ~ 20V | 1.5µs, 1.5µs | - | 4pC | 5pF, 25pF | 5nA | - | -40°C ~ 85°C (TA) | - | - | Surface Mount | 20-PLCC (9x9) |
|
DG390AAKIC SWITCH SPDT X 2 50OHM 16CDIP |
3,211 |
|
规格书 |
- | Tube | Obsolete | SPDT | 2:1 | 2 | 50Ohm | - | 5V ~ 18V | ±5V ~ 18V | 300ns, 250ns | - | 12pC | 14pF, 14pF | 1nA | -74dB @ 500kHz | -55°C ~ 125°C (TA) | - | - | Through Hole | 16-CDIP |
|
|
DG419AKIC SWITCH SPDT X 1 30OHM 8CERDIP |
4,052 |
|
规格书 |
- | Tube | Obsolete | SPDT | 2:1 | 1 | 30Ohm | 3Ohm (Max) | 10V ~ 30V | ±4.5V ~ 20V | 175ns, 145ns | - | 3pC | 8pF, 8pF | 250pA | -85dB @ 1MHz | -55°C ~ 125°C (TA) | - | - | Through Hole | 8-CERDIP |
|
DG303ABKIC SWITCH SPDT X 2 50OHM 14CDIP |
1,628 |
|
规格书 |
- | Tube | Active | SPDT | 2:1 | 2 | 50Ohm | - | 5V ~ 18V | ±5V ~ 18V | 300ns, 250ns | - | 12pC | 14pF, 14pF | 5nA | -74dB @ 500kHz | -25°C ~ 85°C (TA) | - | - | Through Hole | 14-CDIP |
|
MAX4564EKA-TIC SWITCH SPDT X 1 60OHM SOT23-8 |
2,983 |
|
规格书 |
- | Tape & Reel (TR) | Obsolete | SPDT | 2:1 | 1 | 60Ohm | 750mOhm | 1.8V ~ 12V | ±1V ~ 6V | 60ns, 40ns | 450MHz | 3pC | 6pF, 8pF | 1nA | -72dB @ 1MHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | SOT-23-8 |
|
|
DG412AKIC SW SPST-NOX4 30OHM 16CERDIP |
1,031 |
|
规格书 |
- | Tube | Active | SPST - NO | 1:1 | 4 | 30Ohm | 3Ohm (Max) | 10V ~ 30V | ±4.5V ~ 20V | 175ns, 145ns | - | 5pC | 9pF, 9pF | 250pA | -85dB @ 1MHz | -55°C ~ 125°C (TA) | - | - | Through Hole | 16-CERDIP |
|
|
DG419C/DIC SWITCH SPDT X 1 35OHM DIE |
3,206 |
|
规格书 |
- | Tray | Obsolete | SPDT | 2:1 | 1 | 35Ohm | 3Ohm (Max) | 10V ~ 30V | ±4.5V ~ 20V | 175ns, 145ns | - | 3pC | 8pF, 8pF | 250pA | -85dB @ 1MHz | 0°C ~ 70°C (TA) | - | - | Surface Mount | Die |
|
DG508AAKIC MUX 8:1 400OHM 16CERDIP |
3,941 |
|
规格书 |
- | Tube | Active | - | 8:1 | 1 | 400Ohm | 24Ohm | 4.5V ~ 18V | ±4.5V ~ 18V | 1µs, 700ns | - | - | 5pF, 25pF | 500pA | - | -55°C ~ 125°C (TA) | - | - | Through Hole | 16-CERDIP |
|
|
MAX333C/DIC SWITCH SPDT X 4 175OHM DIE |
1,084 |
|
规格书 |
- | Tray | Obsolete | SPDT | 2:1 | 4 | 175Ohm | - | 10V ~ 30V | ±5V ~ 18V | 1µs, 500ns | - | - | 5pF | 5nA | -78dB @ 1MHz | 0°C ~ 70°C (TA) | - | - | Surface Mount | Die |
|
MAX4613EUE+TIC SW SPST-NO/NCX4 70OHM 16TSSOP |
4,598 |
|
规格书 |
- | Tape & Reel (TR) | Active | SPST - NO/NC | 1:1 | 4 | 70Ohm | 4Ohm (Max) | 4.5V ~ 40V | ±4.5V ~ 20V | 250ns, 120ns | - | 5pC | 4pF, 4pF | 500pA | -100dB @ 1MHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | 16-TSSOP |
|
|
DG508ABKIC MUX 8:1 450OHM 16CERDIP |
2,741 |
|
规格书 |
- | Tube | Active | - | 8:1 | 1 | 450Ohm | 27Ohm | 4.5V ~ 18V | ±4.5V ~ 18V | 1.5µs, 1µs | - | - | 5pF, 25pF | 1nA | - | -20°C ~ 85°C (TA) | - | - | Through Hole | 16-CERDIP |
|
DG409AKIC SWITCH SP4TX2 100OHM 16CERDIP |
2,910 |
|
规格书 |
- | Tube | Obsolete | SP4T | 4:1 | 2 | 100Ohm | 1.5Ohm | 5V ~ 30V | ±5V ~ 20V | 150ns, 150ns | - | 2pC | 3pF, 14pF | 500pA | -92dB @ 100kHz | -55°C ~ 125°C (TA) | - | - | Through Hole | 16-CERDIP |
|
|
MAX4613C/DIC SWITCH SPST-NO/NCX4 70OHM DIE |
1,329 |
|
规格书 |
- | Tray | Obsolete | SPST - NO/NC | 1:1 | 4 | 70Ohm | 4Ohm (Max) | 4.5V ~ 40V | ±4.5V ~ 20V | 250ns, 120ns | - | 5pC | 4pF, 4pF | 500pA | -100dB @ 1MHz | 0°C ~ 70°C (TA) | - | - | Surface Mount | Die |
|
|
MAX354MJEIC MUX 8:1 350OHM 16CDIP |
4,916 |
|
规格书 |
- | Tube | Obsolete | - | 8:1 | 1 | 350Ohm | 7Ohm | 4.5V ~ 36V | ±4.5V ~ 18V | 250ns, 200ns | - | 80pC | 1.6pF, 11pF | 500pA | -92dB @ 100kHz | -55°C ~ 125°C (TA) | - | - | Through Hole | 16-CDIP |
|
|
MAX358MJEIC MUX 8:1 1.5KOHM 16CERDIP |
3,593 |
|
规格书 |
- | Tube | Obsolete | - | 8:1 | 1 | 1.5kOhm | - | 4.5V ~ 18V | ±4.5V ~ 18V | 500ns, 500ns | - | - | 5pF, 25pF | 500pA | - | -55°C ~ 125°C (TA) | - | - | Through Hole | 16-CERDIP |
|
MAX4582EEE+C95IC SWITCH SP4T X 2 80OHM 16QSOP |
2,216 |
|
规格书 |
- | Tube | Obsolete | SP4T | 4:1 | 2 | 80Ohm | 1Ohm | 2V ~ 12V | ±2V ~ 6V | 200ns, 100ns | - | 0.5pC | 4pF, 10pF | 1nA | -96dB @ 1MHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | 16-QSOP |
